Video Wall Display – SK-VW4902
Specifications
Panel
-
Model No.: SK-VW4902
-
Panel Size: 49″ DID LCD (Super Narrow Bezel 3.5mm, LED Backlight)
-
Aspect Ratio: 16:9
-
Resolution: 1920 × 1080 (Full HD)
-
Pixel Pitch: 0.53025 × 0.53025 mm
-
Color: 8-bit, 16.7M
-
Brightness: 500 cd/㎡
-
Contrast Ratio: 2000:1
-
Viewing Angle (H/V): 178° / 178°
-
Response Time: ≤ 6ms
-
Life Span: > 60,000 hrs
Image Processing
-
Aspect Ratio: 16:9
-
Quality Compensation Technology: LTI, CTI
-
Motion Compensation: AUTO MOVE
-
Filter: 3D Comb Filtering, Digital Noise Reduction
-
Video Standards: PAL, NTSC
Inputs & Control
-
Digital Inputs:
-
HDMI × 1 (1920×1080 @ 60Hz, backward compatible)
-
DVI (DVI-I) × 1 (1080p backward compatible)
-
-
Other Interfaces:
-
RJ45 × 2
-
USB × 1
-
RS232 (Centralized Control)
-
-
Video Wall Controller: Built-in (each screen)
Power
-
Power Supply: AC 100–240V
-
Max Power Consumption: 230W
-
Standby Power Consumption: ≤ 3W
Structure
-
Bezel Width:
-
Top: 2.25mm
-
Bottom: 1.25mm
-
Left: 2.25mm
-
Right: 1.25mm
-
-
Dimensions (W×H×D): 1077.58 × 607.8 × 109.5 mm (reference)
-
Net Weight: 27kg
-
Shell Material: Metal (anti-static, anti-magnetic, anti-interference)
-
Installation: Wall mount, floor stand, hanging mount
Environment
-
Operating Temperature: 0℃ ~ 50℃
-
Storage Temperature: -20℃ ~ 65℃
-
Operating Humidity: 20%–80%
